Product description

Recommended Uses

High Gloss MDF Board is suitable for use on fine quality residential and contract furniture, casework, and also for architectural application on inside wall, interior doors and sliding door systems. - INDOOR USES ONLY.

Product Composition

(Impregnating Step)

The decorative or matte paper is impregnated with melamine resin.

(Pressing the impregnated paper on the board)

Pressing the impregnated (decorative or mat) paper on the MDF board.

(Coating Step)

Decorain uses the MDF (medium density fiberboard) that is coated 6 times with paint and 6 times with UV varnish – for boards that are in plain and for the decorative boards color 6 layers of UV coating is used. Only one side of the board is coated.

(Packting Step)

Patterns & Colors

Available in the full range of Decorain High Gloss MDF Board solid pearl and patterns. E-mail us with your company details and the address and we will send them to you free of charge. Please see the actual samples before ordering.

Tehnical data

Glossmeter reading : G100

Note : Glossometer reading are made at the angle of 60°.

Standard Board Width: 1220mm

Standard Board Length: 2440mm

NOTE : Cutting sizes and edge work are available as an order. Please check with your Decorain High Gloss MDF Board representative.

Thickness and Weight

Description:	Decorain high gloss mdf board
Thickness:	18mm+0,8mm, 9mm+0,8mm
Weight per board (18mm):	33 kg + / - 0,4 kg,

Physical Properties of General Purpose Decorain High Gloss MDF Board..

Items		Test Results	Testing Method
Density (g/cm3)		0.69	KS F 3200:2006
Moisture contents (%)		7
Bending strngth (N/mm2)	Lenght	40.5
	Widith	38.1
Expansion ratio in thickness due to water absortion (%)		1
Wood screw holding power (N)	Face	703
	Edge	450
Adhesiveness (class)		1
Pencil hardness - Woff Wilborn method		2H	KS M ISO 15184 : 2002
Fouling resistance	Bean oil		KS M 3510 : 2005
	Lubricating oil
	95% Ethanol
	Cement paste
	10% Amonia water
	Milk
	5% Acetic acid
	5% Hydrochloric acid
	Kerosene

Appearance

• It is acceptable that board has some spot within 100mm from edge side.
• Spots, dirt and similar surface defects. The diameter (dirt,spots,etc.) shall not exceed 2.0mm per sheet, with a maximum of 2 spots per sheet (not all of the boards will have spots).
• Fibres, hairs, etc. total length of fibrous contamination shall not exceed 5mm per ㎡ of sheet area.

The total permissible contamination may be in the form of a single defect or dispersed over a number of smaller defects.
